| System Physical Standard Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Product Form | Product Form | 2 in 1 | ||||
| Dimensions | 258*173*9mm /258*173*8.5mm | |||||
| Weight | tablet:597gkeyboard:563g | |||||
| LCD | Screen Size | 10.1‘ 10:16 | ||||
| Screen Resolution | 1280*800/1920*1200 IPS Screen | |||||
| electromagnetic screen | Digital pen of handwriting (optional) | |||||
| TP | Touch Module | 10 Point Capacitive | ||||
| Battery | Type | Lithium-ion polymer battery | ||||
| Capacity | 3.7V/6000-8000mAh | |||||
| Endurance | 6-8 Hours | |||||
| System hardware configuration: | ||||||
| Type | Details | Descriptions | ||||
| CPU | Type | Cherry Trail Z8300/Z8350 /Apollo Lake N3350/N3450 /N4200 14nm | ||||
| Speed | Up to 1.84GHZ(1/2 cores) Up to 1.6 GHZ(3/4 cores) |
|||||
| GPU | Type | Intel HD Gen8·BLP 10/12 EU up t 600MHZ | ||||
| RAM | Capacity | LPDDR3 2G/4G（Optional） | ||||
| ROM Flash | Capacity | eMMC 32GB/64GB/128GB（Optional） | ||||
| Camera | Front | 0.3MP/2.0MP（Optional） | ||||
| Rear | 2.0MP/5.0MP（optional） | |||||
| Speaker | Size | Built-in 8Ω/0.8W speaker x 2 | ||||
| GPS | Internal | YES | ||||
| G-sensor | Built-in | Gravity acceleration sensor | ||||
| Network Connections: | ||||||
| Type | Details | Descriptions | ||||
| WIFI | WIFI module | WIFI 802.11/b/g/n or a/b/g/n+BT+(NFC optional) | ||||
| 3G/4G network | Built-in | WCDMA (Fibocom H350) (900/2100mHz or 850/1900mHz) (optional) | ||||
| Ethernet Network | MiNi USB switch to Ethernet Network | Supportive | ||||
| Interface Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Memory card socket | External memory | Support SDHC/SDXC | ||||
| SIM card socket | Data supportive | Full Size SIM | ||||
| USB interface | Data transfer supportive | Full size USB2.0 | ||||
| USB interface | Data transfer supportive | Micro USB | ||||
| Headphone jack | Music output | ∮ 3.5mm standard headphone jack | ||||
| DC connector | Power | ∮ 2.5MM power connector | ||||
| HDMI interface | Video output | HDMI Type C 1.4a | ||||
| Keyboard | Input device | Pogo pin connect | ||||
| Mouse | Input device | USB、BT Expuntable Wired / Wireless Supportive | ||||
| Necessary Accessories: | ||||||
| Type | Details | Descriptions | ||||
| 3.5-inch headphone | Standard Configuration | Standard stereo headphones | ||||
| Power adapter | Standard Configuration | DC 5V/2A | ||||
| USB patch cord | Standard Configuration | HOST | ||||
| Software Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Operating System | Operating system version | Windows10 | ||||
| office | yes | |||||
